Fujifilm Dimatix Spectra Polaris PQ-512/85 AAA Printhead (85 pL)
- Write a review
$868.00
The Genuine New Dimatix Spectra Polaris PQ512/85PL printhead is an authentic 512-channel piezoelectric drop-on-demand assembly featuring an 80 pL calibrated drop size (adjustable up to 150 pL), high-speed 50 kHz firing frequency, VersaDrop™ technology, and support for 1 or 2 color operation on industrial printers like Kornit Avalanche 1000.
Genuine Spectra Polaris PQR-512 85PL (PQ-512/85 AAA) Printhead – Original OEM
The Spectra® Polaris PQR-512 85PL (official model PQ-512/85 AAA) is a high-performance industrial piezoelectric drop-on-demand printhead manufactured by Fujifilm Dimatix. It is designed for a broad range of industrial and commercial printing applications, particularly textile and high-coverage production environments such as Kornit Avalanche and Storm systems.
The printhead features 512 independent channels arranged in multiple rows. In single-colour mode it operates at 200 dpi (127 μm nozzle spacing); in two-colour mode it operates at 100 dpi (254 μm spacing). It delivers a calibrated 80 picoliter native drop size with VersaDrop™ binary jetting capability, adjustable from 80 to 150 pL. Nominal drop velocity is 8 m/s. Maximum firing frequency is 20 kHz at 80 pL (10 kHz at 150 pL). Operating temperature is supported up to 60°C.
One Polaris PQR-512 85PL assembly consists of two Polaris PQR-256 85PL modules and uses a repairable design with field-proven materials for long service life and consistent output. The unit is dual-ported for efficient flushing and recirculation and includes integral heaters and temperature sensors.
We strongly recommend replacing the head cables when installing a new printhead. This is a genuine Spectra / Fujifilm Dimatix OEM product manufactured in the USA and carries the manufacturer warranty.
Part Information
| Parameter | Detail |
|---|---|
| Product Name | Genuine Spectra Polaris PQR-512 85PL Printhead |
| Manufacturer | Fujifilm Dimatix / Spectra |
| Official Model | PQ-512/85 AAA |
| Commercial Designation | PQR-512 85PL |
| Construction | Two Polaris PQR-256 85PL modules (repairable design) |
| Condition | Original Brand New (Factory Sealed) |
| Ink Compatibility | UV-curable, organic solvent and aqueous inks |
| Country of Origin | USA |
| Industrial Application | Textile printing (Kornit systems), industrial and commercial high-coverage applications |
Technical Specifications
| Parameter | Value |
|---|---|
| Technology | Piezoelectric Drop-on-Demand with VersaDrop™ binary jetting |
| Active Nozzles | 512 |
| Print Width | 64.897 mm (2.555") |
| Nozzle Spacing (Single Colour) | 127 μm (0.005") – 200 dpi |
| Nozzle Spacing (Two Colour) | 254 μm (0.010") – 100 dpi |
| Native Drop Size | 80 pL |
| Adjustable Binary Range | 80 – 150 pL |
| Maximum Resolution | Up to 400 dpi |
| Firing Frequency | 20 kHz at 80 pL / 10 kHz at 150 pL |
| Nominal Drop Velocity | 8 m/s |
| Operating Temperature | Up to 60°C |
| Fluid Viscosity Range | 8 – 20 cP |
| Ink Compatibility | UV-curable, organic solvent and aqueous inks |
| Dry Weight | 160 g |
Construction & Family Notes
| Reference | Description |
|---|---|
| PQR-512 85PL / PQ-512/85 AAA (Current) | 512-channel assembly consisting of two PQR-256 85PL modules |
| PQR-256 85PL | Individual 256-channel module that can be separated for field repair |
| Polaris Family | Also available in 15 pL and 35 pL native drop versions (PQ-512/15 AAA and PQ-512/35 AAA) |
Note: The repairable design allows individual 256-channel modules to be exchanged in the field without special tools when the mounting bezel is used.
Technical Precision & Operational Advisory
Installation Warning
Installation, alignment and electrical connection must be performed by a qualified technician following the official printer manufacturer procedures. Incorrect handling can permanently damage the piezo channels or drive electronics.
- ESD Protection: Always use a grounded anti-static wrist strap when handling the printhead. Piezo actuators are highly sensitive to electrostatic discharge.
- Power Isolation: Completely power down the printer and isolate carriage drive power before connecting or disconnecting the printhead.
- Cable Replacement: It is strongly recommended to replace the head cables when installing a new printhead to avoid intermittent connection issues.
- Ink Compatibility: Use only UV-curable, solvent or aqueous inks approved for the specific system. Non-approved fluids can damage the head and void warranty.
- Handling Factory-Sealed Unit: Do not break the seal until ready for installation. Once the printhead has been exposed to ink or installed, it is considered used and cannot be returned.
- Warranty Exclusions: Damage caused by non-original inks, misuse, lack of maintenance, improper storage, or third-party components is expressly excluded from warranty coverage.
Compatible Models & Systems
The Spectra Polaris PQR-512 85PL is confirmed compatible with the following Kornit systems:
- Kornit Avalanche Hexa R
- Kornit Avalanche R series
- Kornit Storm Hexa
Recommendation: Always verify the exact part number on the existing printhead and consult the machine service documentation before ordering. Compatibility can vary by specific configuration and firmware revision.
Terms, Warranty & Customer Protection
Authentic OEM Guarantee: 100% original Spectra / Fujifilm Dimatix manufactured component. Country of origin: USA. Each unit is factory-sealed and inspected before shipment.
Manufacturer Warranty: This printhead carries the official manufacturer warranty. Warranty does not cover defects related to non-original inks, misuse, lack of maintenance, improper storage, third-party components, or cosmetic issues.
Unopened Return Policy: Returns accepted only for unopened, uninstalled items in original factory-sealed packaging.
Final Sale Conditions: Once the printhead has been exposed to ink, installed, or the factory seal broken, it is considered used and cannot be returned or exchanged due to chemical contamination risks and electronic safety regulations.
