Genuine Datamax H-Class H-4606 600 DPI Ultra-High Resolution Printhead 20-2243-01
- Write a review
$945.00
$548.10
Save 42%
Authentic OEM 600 DPI ultra-high-definition thermal printhead assembly for Datamax-O'Neil H-Class H-4606 industrial printers. Engineered for microscopic circuit board tags, medical specimen vials, and high-density 2D Data Matrix codes up to 6 ips. Unsurpassed microscopic print clarity.
Product Overview
The Genuine Datamax 20-2243-01 (PHD20-2243-01) thermal printhead represents the absolute peak of print resolution for the Datamax H-Class series, delivering an incredible 600 DPI (24 dots/mm) for the H-4606 and A-Class Mark II A-4606 industrial printers. Designed specifically for electronic component tracking, pharmaceutical packaging, and laboratory micro-labeling, this printhead allows sharp rendering of miniature 2-point fonts and microscopic 2D Data Matrix codes. Engineered with a durable protective hard-glaze coating, it ensures uniform thermal dissipation and high-speed scan compliance under automated vision inspection systems.
Part Information
| Product Name | Genuine Datamax H-Class H-4606 600 DPI Ultra-High Resolution Printhead 20-2243-01 |
| Manufacturer / Brand | Datamax |
| OEM Part Number / Reference | 20-2243-01 |
| Condition | 100% Genuine Original, Brand New, Factory Sealed |
| Product Status | Active OEM Production / Grade A Standard |
Technical Specifications
| Parameter | Technical Value / Specification |
|---|---|
| Technology | Thermal Transfer / Direct Thermal (Micro Thin Film) |
| Resolution / Channels | 600 DPI (23.6 / 24 dots/mm) |
| Print Width / Geometry | 4.16 inches (105.7 mm) |
| Operating Performance | Print Speed up to 6 ips (152 mm/sec) |
| Technical Details & Notes | Dot pitch 0.042 mm (2496 total micro-heating elements); heavy-duty precision heatsink chassis; optimized for ultra-smooth synthetic media, polyimide Kapton labels, and premium full-resin thermal transfer ribbons. |
Master Comparison Matrix
| Model Variant | OEM Reference | Technology | Primary Application | Status |
|---|---|---|---|---|
| Genuine Datamax H-Class H-4606 600 DPI Ultra-High Resolution Printhead 20-2243-01 (CURRENT PRODUCT) | 20-2243-01 | Thermal Transfer / Direct Thermal (Micro Thin Film) | Industrial Production | Active Genuine |
Technical Precision & Operational Advisory
- Electrostatic Discharge (ESD) Protection: Always wear a grounded anti-static wrist strap during handling to avoid damaging sensitive internal circuitry.
- Power Isolation Protocols: Complete electrical power-down must be verified prior to disconnecting or reconnecting ribbon cables. Never hot-plug connections.
- Operational Precision: Micro-elements are extremely susceptible to electrostatic discharge; grounding wrist straps are strictly mandatory during installation. Never scrape the ceramic glaze with metallic tools. Clean meticulously with lint-free microfiber wipes and 99.7% Isopropyl Alcohol after every roll of ribbon to maintain dot line integrity.
- Certified Technician Requirement: Physical mounting and electrical alignment must be conducted exclusively by trained industrial service personnel.
Compatible Models & Systems
| Manufacturer / Brand | Verified Compatible Models & Systems |
|---|---|
| Datamax | Datamax-O'Neil H-Class H-4606, Datamax-O'Neil A-Class Mark II A-4606 (600 dpi models) |
Terms, Warranty & Customer Protection:
Pre-Installation Guarantee: 100% brand-new, factory-original product. Each unit is inspected and sealed before shipment. We guarantee authenticity and factory condition upon arrival.
Store Warranty Policy: 30 working days warranty covering manufacturing defects. Warranty claims require complete unboxing video and professional installation video performed by an experienced technician following standard recommended procedures.
Final Sale Conditions: Once the printhead has been exposed to ink or installed into a printer, it is considered used and cannot be returned or exchanged. Please verify compatibility and installation readiness before opening the sealed packaging.
