- On sale!
- -42%
- New
Datamax-O'Neil MicroFlash 2te Thermal Printhead 203 DPI 210254-001
- Write a review
$170.00
$98.60
Save 42%
Authentic OEM 203 DPI thermal printhead for Datamax-O'Neil MicroFlash 2te and 2t ultra-compact mobile printers. Provides clean 2-inch wide direct thermal receipt printing for route distribution and field service. Genuine factory replacement component.
Product Overview
The Datamax-O'Neil 210254-001 is a genuine 203 DPI (8 dots/mm) replacement thermal printhead assembly engineered for the MicroFlash 2t and 2te compact mobile printer line. Supporting a 1.90-inch (48 mm) active print path, this compact head produces legible text, numerical audit logs, and 1D/2D barcodes on portable direct thermal receipt stocks. Constructed for long-term reliability in field operations, it offers high thermal response and low current draw suitable for battery-operated machinery. Proper cleaning using lint-free isopropyl alcohol swabs extends printhead life and prevents element burnout from paper dust accumulation.
Part Information
| Product Name | Datamax-O'Neil MicroFlash 2te Thermal Printhead 203 DPI 210254-001 |
| Manufacturer / Brand | Honeywell |
| OEM Part Number / Reference | 210254-001 |
| Condition | 100% Genuine Original, Brand New, Factory Sealed |
| Product Status | Active OEM Production / Grade A Standard |
Technical Specifications
| Parameter | Technical Value / Specification |
|---|---|
| Technology | Direct Thermal |
| Resolution / Channels | 203 DPI |
| Print Width / Geometry | 1.90 in (48 mm) |
| Operating Performance | High-Speed Jetting Standard |
| Technical Details & Notes | Technology: Direct Thermal; Resolution: 203 DPI (8 dots/mm); Maximum Print Width: 1.90 in (48 mm); Operating Mode: Direct thermal; Component Type: Ultra-compact mobile thermal printhead assembly |
Master Comparison Matrix
| Model Variant | OEM Reference | Technology | Primary Application | Status |
|---|---|---|---|---|
| Datamax-O'Neil MicroFlash 2te Thermal Printhead 203 DPI 210254-001 (CURRENT PRODUCT) | 210254-001 | Direct Thermal | Industrial Production | Active Genuine |
Technical Precision & Operational Advisory
- Electrostatic Discharge (ESD) Protection: Always wear a grounded anti-static wrist strap during handling to avoid damaging sensitive internal circuitry.
- Power Isolation Protocols: Complete electrical power-down must be verified prior to disconnecting or reconnecting ribbon cables. Never hot-plug connections.
- Operational Precision: Power off the printer and remove the battery pack prior to maintenance. Use ESD safety measures when handling the internal flexible circuitry. Ensure the connector clip is fully engaged and the printhead alignment pins sit flat in their carrier slots. Wipe the heating elements with 99% pure isopropyl alcohol before feeding paper.
- Certified Technician Requirement: Physical mounting and electrical alignment must be conducted exclusively by trained industrial service personnel.
Compatible Models & Systems
| Manufacturer / Brand | Verified Compatible Models & Systems |
|---|---|
| Honeywell | Datamax-O'Neil: |
Terms, Warranty & Customer Protection:
Pre-Installation Guarantee: 100% brand-new, factory-original product. Each unit is inspected and sealed before shipment. We guarantee authenticity and factory condition upon arrival.
Store Warranty Policy: 30 working days warranty covering manufacturing defects. Warranty claims require complete unboxing video and professional installation video performed by an experienced technician following standard recommended procedures.
Final Sale Conditions: Once the printhead has been exposed to ink or installed into a printer, it is considered used and cannot be returned or exchanged. Please verify compatibility and installation readiness before opening the sealed packaging.
210254-001
200 Items
