Konica Minolta KM1024aSHE 6pl Analogue Waveform Industrial Inkjet Printhead
- Write a review
$1,490.00
The Konica Minolta KM1024aSHE is a high-performance 1024-nozzle piezo printhead featuring analogue waveform drive for superior drop control and flexibility. With a native 6 pl drop volume, independent nozzle architecture and compatibility with UV, solvent and oil-based inks, it delivers precise imaging and reliable productivity for industrial single-pass systems.
Product Overview
The Konica Minolta KM1024aSHE is an advanced industrial inkjet printhead designed for high-speed single-pass and multi-pass systems that benefit from analogue waveform flexibility. Featuring an independent drive system and a precise multi-row nozzle architecture, it supports 1024 nozzles across a 72 mm print width. The native 6 pl binary drop volume (with multi-drop greyscale capability up to approximately 20–24 pl) combined with analogue waveform control enables finer tuning of drop formation, velocity and volume for improved image quality and ink efficiency. An integrated heater supports stable jetting with UV-curable, solvent and oil-based inks across a typical operating range of room temperature to 55 °C, making this model ideal for applications requiring high productivity, reliability and precise fluid control.
Part Information
- Brand: Konica Minolta
- Product Type: Industrial Inkjet Printhead
- Technology: Piezoelectric Drop-on-Demand (Independent Drive, Analogue Waveform)
- Ink Type Compatibility: UV-curable, Solvent, Oil-based
- Condition: 100% Genuine Original, Brand New
- Country of Origin: Japan
Technical Specifications
| Native Resolution | 360 npi |
| Number of Nozzles | 1024 |
| Native Drop Volume | 6 pl (Binary) / up to ~20–24 pl (4-drop greyscale) |
| Regular Jetting Frequency | 40 kHz (Binary) / ~22–24 kHz (4dpd greyscale) |
| Print Width | 72 mm |
| Greyscale Levels | Up to 8 levels |
| Drive / Waveform | Independent drive with Analogue waveform |
| Internal Heater | Yes (integrated) |
| Jetting Temperature Range | RT – 55 °C |
| Ink Viscosity | Typically 7–10 mPa·s |
| Dimensions (W × D × H) | Approx. 131.2 mm × 17.6 mm × 97 mm |
| Weight | Approx. 150 g |
| Compatible Ink Types | UV-curable, Solvent, Oil-based |
Technical Precision & Operational Advisory
- Strict ESD protection is mandatory during handling and installation. Always use grounded wrist straps, anti-static work surfaces and proper packaging procedures.
- Ensure complete power isolation of the printer and drive electronics before installing or removing the printhead.
- Replace all ink supply tubes, filters, dampers and connectors when installing a new head to prevent contamination and maintain optimal flow.
- Prepare fluids correctly: filter ink to the manufacturer-recommended micron rating and follow any required degassing or conditioning procedures for the specific ink chemistry.
- Maintain stable operating temperature using the integrated heater and external system controls within the recommended RT–55 °C range. Avoid rapid temperature changes.
- Use only the exact analogue waveform, voltage and meniscus pressure settings specified by the printer OEM or drive electronics supplier. Analogue waveform flexibility requires precise tuning for optimal drop formation.
- Adhere strictly to the machine’s cleaning, capping and maintenance schedule. Never leave the nozzle plate exposed or dry for extended periods.
Compatible Equipment & Applications
| Compatible Printer Brands / Models | Industrial single-pass and multi-pass systems designed or configured for the KM1024aSHE analogue-waveform architecture (confirm exact compatibility with machine documentation and drive electronics) |
| Primary Applications | High-resolution single-pass UV, solvent and oil-based printing, industrial decoration, packaging, signage & display, PCB and functional printing, and continuous production environments requiring analogue waveform flexibility and precise drop control |
| Typical Use Case | OEM replacement or system upgrade for production printers needing 6 pl native drop volume, analogue waveform capability, 360 npi resolution and reliable UV/solvent/oil performance |
Terms, Warranty & Customer Protection:
- Pre-Installation Guarantee: 100% brand-new, factory-original product. Each unit is inspected and sealed prior to shipment. Visual and electrical verification available upon request before installation.
- Store Warranty Policy: 30 working days warranty covering manufacturing defects under correct installation and operation according to OEM guidelines. Proof of proper handling and system parameters may be required.
- Final Sale Conditions: Once the printhead has been exposed to ink or installed in a printer, it is considered used and non-returnable except in cases of verified manufacturing defect. Incorrect installation, contamination, ESD damage or use with non-approved inks voids all warranty.
