Zebra ZT410 / ZT411 203 DPI Thermal Printhead Kit (OEM P/N: P1058930-009)
- Write a review
$195.00
$113.10
Save 42%
Original OEM 203 DPI thermal printhead kit designed specifically for Zebra ZT410 and ZT411 industrial barcode printers. Delivers razor-sharp barcode symbologies, fast throughput up to 14 ips, and dependable durability for high-volume logistics and warehousing environments. Engineered for seamless drop-in field replacement without firmware conflicts.
GENUINE OEM REPLACEMENT • PRECISION THERMAL HARDWARE
Zebra ZT410 / ZT411 203 DPI Thermal Printhead Kit (OEM P/N: P1058930-009) – Genuine OEM Replacement
OEM Part Number: P1058930-009 • Core Engine: Industrial Mid-Range Thin-Film Thermal Array (8 dots/mm) • Target Platform: Zebra ZT400 Series 4-Inch Industrial (ZT410 & ZT411 203 DPI)
The Zebra ZT410 / ZT411 203 DPI Thermal Printhead Kit (OEM P/N: P1058930-009) is an authentic, high-durability electro-thermal imaging assembly engineered specifically for Zebra ZT400-Series mid-range industrial label printers. Fabricated to uncompromising OEM semiconductor cleanroom standards by Zebra Technologies Corporation, this printhead assembly delivers robust heat transfer efficiency, exceptional contrast, and razor-sharp edge definition across high-volume distribution, warehouse logistics, manufacturing automation, asset management, and retail compliance labeling. Purpose-built for rugged multi-shift operations, the unit demonstrates outstanding wear resistance against continuous abrasive media passage and repetitive thermal shock cycles.
At its architectural foundation, the assembly integrates a 4.09-inch (104.0 mm) transverse ceramic substrate populated with 832 active micro-resistor heating dots arrayed at an intrinsic spatial density of 203 dots per inch (8 dots/mm, nominal 0.125 mm dot pitch). Integrated high-frequency onboard driver ICs and shift registers regulate microsecond pulse-width strobe cycles, supporting sustained industrial throughput velocities reaching up to 14.0 inches per second (356 mm/sec) on standard 203 DPI media runs. The active heating line is fortified with an advanced diamond-like carbon (DLC) and silicon nitride (Si3N4) anti-abrasion protective overcoat glaze, coupled with an onboard negative temperature coefficient (NTC) thermistor network that ensures continuous closed-loop thermal compensation across high-speed duty cycles.
Pre-assembled on a precision-machined, high-thermal-conductivity aluminum heatsink carriage bracket measuring approximately 135 mm × 36 mm × 28 mm with an unprimed assembly weight of approximately 115 grams, the module incorporates factory pivot dowels and self-leveling spring notches configured specifically for the ZT400 toggle-bar mechanism. Direct electrical interconnectivity is established via dual high-grade gold-plated multi-pin PCB header sockets, minimizing electrical contact resistance and transient impedance across high-current strobe rails. Each P1058930-009 replacement kit is delivered as a 100% genuine factory-sealed OEM unit sealed inside certified electrostatic discharge (ESD) and moisture-vapor barrier shielding, safeguarding sensitive micro-circuitry prior to commissioning.
Critical Resolution & Width Architecture Verification: Prior to procurement, verify the exact model configuration code and resolution on your printer's regulatory serial nameplate. Part number P1058930-009 is engineered exclusively for 4-inch 203 DPI chassis (ZT410 & ZT411). It cannot be installed into 300 DPI carriages (P/N: P1058930-010), 600 DPI carriages (P/N: P1058930-011), or 6-inch wide-format ZT420/ZT421 platforms (P/N: P1058930-012) without complete mechanical drive, platen, sensor, and firmware configuration conversion.
ENGINEERING REFERENCE
Identification Notes & Core Distinction
| Reference Parameter | Engineering Specification & Description |
|---|---|
| Current Official OEM P/N | P1058930-009 (Zebra Global Spares Standard Kit Part Number). |
| Model Series Interoperability | Fully interoperable between ZT410 and ZT411 203 DPI platforms. Features backward-compatible mounting frame and universal sensor clearance. |
| Legacy Predecessor Distinction | Supersedes previous generation ZM400 / Z4M Plus printheads (OEM P/N: 79800M). P1058930-009 utilizes updated connector socket positions and revised heatsink mounting profiles incompatible with ZM400 chassis. |
| Resolution Disqualification | Strictly incompatible with 300 DPI (P1058930-010) or 600 DPI (P1058930-011) carriages. Element resistance rankings, strobe drive sequences, and platen drive pulley ratios are electrically and mechanically distinct. |
Notice: This printhead is dedicated solely to 4-inch wide ZT410 and ZT411 industrial chassis operating at 203 DPI. Do not attempt retrofit installations into 6-inch wide ZT420/ZT421 units or Xi4-series industrial engines without verified model matching.
Part Information Matrix
| Product Official Designation | Zebra ZT410 / ZT411 203 DPI Thermal Replacement Printhead Kit |
| OEM Manufacturer & Assembly Fab | Zebra Technologies Corporation (Industrial Printing Solutions Operations) |
| Exact Model Identification | Zebra ZT400 Series 4-inch 203 DPI Thermal Line Sub-Assembly |
| OEM Part Number (P/N) | P1058930-009 |
| Known Superseded Aliases | P1058930-009-A, ZEB-P1058930009, KIT PRINTHEAD 203DPI ZT410/ZT411 |
| Print Technology Compatibility | Thermal Transfer (Wax, Wax-Resin, Full Resin Ribbons) & Direct Thermal (Heat-Sensitive Papers/Synthetics) |
| Product Lifecycle Status | Active OEM Production & Tier-1 Spares Maintenance Support |
| Physical Condition | • 100% Brand New, Factory Sealed in Original OEM Anti-Static Moisture Barrier Packaging |
| Country of Origin | Japan / USA (Zebra Certified Semiconductor & Assembly Operations) |
| Primary Industrial Application | High-Volume Distribution Shipping Labels, Automotive Parts Compliance, Pallet Invoices, Cross-Dock Logistics Barcoding |
Technical Specifications Matrix
| Engineering Metric | Certified Parameter Value |
|---|---|
| Native Print Resolution | 203 DPI (8 dots per mm / nominal 0.125 mm dot pitch) |
| Total Active Heating Dot Count | 832 individual micro-resistor elements aligned in a contiguous linear array |
| Maximum Active Print Width | 4.09 inches (104.0 mm) continuous transverse imaging line |
| Maximum Rated Print Speed | Up to 14.0 inches per second (356 mm/sec) under optimal toggle pressure |
| Nominal Dot Resistance | Calibrated factory resistance rank ~650 – 850 Ω (stamped on barcode rank label) |
| Protective Overcoat Glaze | Diamond-Like Carbon (DLC) & Silicon Nitride (Si3N4) anti-abrasion glaze |
| Operating Thermal Range | 5°C to 40°C (40°F to 104°F) operating environment; monitored via onboard NTC thermistor |
| Logic & Strobe Drive Voltage | +5.0V DC logic drive rail; +24.0V DC ±5% nominal head strobe power rail |
| Dimensions & Physical Mass | Approx. 135 mm × 36 mm × 28 mm | Dry assembly net weight: ~115 g |
| Electrical Interconnect Interface | Dual high-conductivity gold-plated multi-pin PCB header sockets |
FIELD ADVISORY
Technical Precision & Installation Warning
ATTENTION: Industrial thermal printheads are electrostatic-sensitive semiconductor assemblies operating under high electrical current. Installation and toggle alignment must strictly be executed by qualified service engineers or certified hardware personnel in accordance with Zebra ZT400-Series maintenance manuals.
- ESD Protection: Onboard driver ICs and shift register circuits are acutely vulnerable to electrostatic breakdown. Technicians must touch an earthed chassis point or wear a grounded anti-static wrist strap before opening the protective ESD shielding or handling the printhead harness contacts.
- Power Isolation & Absolute Prohibition of Hot-Swapping: Disconnect AC mains power from the rear power entry module and wait at least 60 seconds for internal reservoir capacitors to bleed down before disconnecting the printhead cables. Seating or unseating harness connectors while power is active will cause electrical arcing across 24V strobe pins, destroying mainboard driver MOSFETs and permanently blowing printhead channels.
- Cable / Harness Inspection: Thoroughly inspect the dual wiring harnesses for pinched insulation, copper fatigue, or oxidized pins. Verify that both multi-pin connectors are seated squarely and latched securely; misaligned or loose insertion can cross 24V power traces into low-voltage logic lines, destroying the main logic board.
- Ink / Fluid Chemical Compatibility: Clean the micro-resistor heating line exclusively with pure 99.7% electronic-grade Isopropyl Alcohol (IPA) using lint-free foam swabs. Never use metal scrapers, razor blades, abrasive textiles, or chlorinated chemical solvents to clear baked-on ribbon residue; scratching the protective DLC glaze permanently severs dot continuity.
- Handling Factory-Sealed Unit: Never touch the mirror-finished ceramic burn line with bare fingertips. Natural skin oils, acids, and salts will bond to the resistive glass glaze, charring under sustained operational heat and causing localized element burnout.
- Part Number & Pressure Calibration: Ensure the factory toggle pressure blocks are adjusted symmetrically across the 4-inch platen roller to prevent ribbon wrinkling and premature edge wear. After replacement, verify printhead resistance calibration and darkness settings via the ZT411 touch display or ZT410 front panel configuration menu.
Target Equipment Compatibility Matrix
Zebra ZT410 Industrial Platform (203 DPI)
- Zebra ZT410 Standard Industrial Printer (203 DPI)
- Zebra ZT410 Thermal Transfer & Direct Thermal Models
- Zebra ZT410 RFID UHF Encoder Configurations (203 DPI)
- Model Codes: ZT41042-xxxxxxx / ZT41042-Txxxxxx
Zebra ZT411 Industrial Platform (203 DPI)
- Zebra ZT411 Color Touch Display Industrial Printer (203 DPI)
- Zebra ZT411 On-Metal RFID & Standard UHF Models
- Zebra ZT411 Thermal Transfer & Direct Thermal Chassis
- Model Codes: ZT41142-xxxxxxx / ZT41142-Txxxxxx
Incompatible Equipment Alert (Do Not Procure for the Following Platforms):
This assembly is strictly NOT COMPATIBLE with 300 DPI versions of the ZT410/ZT411 (OEM P/N: P1058930-010), 600 DPI versions (OEM P/N: P1058930-011), 6-inch wide ZT420/ZT421 models (OEM P/N: P1058930-012 / P1058930-013), legacy ZM400 / Z4M units (OEM P/N: 79800M), nor Xi4-Series industrial printers. Always verify the printer serial nameplate and existing part number prior to commissioning.
Terms, Warranty & Customer Protection Policy
1. Pre-Installation Guarantee: Every printhead kit is guaranteed to be 100% genuine Zebra OEM, factory-fresh, sealed in original anti-static moisture-barrier packaging, and completely free of missing dot elements, electrical opens, or shorts upon delivery.
2. Store Warranty Policy: We provide a 30 working-day store warranty against dead-on-arrival (DOA) electrical defects from the recorded delivery date. Warranty claims require an unedited, continuous video recording showing unboxing of the intact factory seal and full physical installation by a qualified technician, including cable connection verification and self-test configuration printout.
3. Final Sale Conditions: Due to the sensitive semiconductor characteristics of micro-resistor thermal heating arrays, all sales are strictly final once the anti-static vacuum seal is breached or the printhead is mounted to the printer chassis. Scratched protective glaze, physical chipping from sharp tools or staples, reverse voltage destruction, heat burnout from extreme darkness settings, or ribbon wrinkle adhesive contamination are explicitly excluded from warranty coverage.
