Datamax-O'Neil A-6212 Mark II Thermal Printhead 203 DPI PHD20-2275-01
- Write a review
$790.00
$458.20
Save 42%
Authentic OEM 203 DPI wide-format thermal printhead for Datamax-O'Neil A-Class Mark II A-6212 print engines. Engineered for 6-inch wide pallet, compliance, and industrial outer-case labeling automation. Direct drop-in replacement built to sustain continuous industrial production speeds.
Product Overview
The Datamax-O'Neil PHD20-2275-01 is a wide-format 203 DPI thermal printhead engineered specifically for the A-Class Mark II A-6212 industrial print engine. Accommodating print widths up to 6.40 inches (162.6 mm), it facilitates full-size ODETTE, AIAG, and GS1-128 shipping and compliance label generation in high-speed automated packaging cells. The robust construction supports direct thermal and thermal transfer workflows, featuring an optimized resistive configuration to distribute current evenly across the extended line. Regular maintenance and balanced mechanical downforce across the wide chassis are critical to avoid premature center-line wear and uneven transfer.
Part Information
| Product Name | Datamax-O'Neil A-6212 Mark II Thermal Printhead 203 DPI PHD20-2275-01 |
| Manufacturer / Brand | Honeywell |
| OEM Part Number / Reference | PHD20-2275-01 |
| Condition | 100% Genuine Original, Brand New, Factory Sealed |
| Product Status | Active OEM Production / Grade A Standard |
Technical Specifications
| Parameter | Technical Value / Specification |
|---|---|
| Technology | Direct Thermal / Thermal Transfer |
| Resolution / Channels | 203 DPI |
| Print Width / Geometry | 6.40 in (162.6 mm) |
| Operating Performance | High-Speed Jetting Standard |
| Technical Details & Notes | Technology: Direct Thermal / Thermal Transfer; Resolution: 203 DPI (8 dots/mm); Maximum Print Width: 6.40 in (162.6 mm); Operating Mode: Thermal transfer and direct thermal; Component Type: Wide-format thermal printhead assembly |
Master Comparison Matrix
| Model Variant | OEM Reference | Technology | Primary Application | Status |
|---|---|---|---|---|
| Datamax-O'Neil A-6212 Mark II Thermal Printhead 203 DPI PHD20-2275-01 (CURRENT PRODUCT) | PHD20-2275-01 | Direct Thermal / Thermal Transfer | Industrial Production | Active Genuine |
Technical Precision & Operational Advisory
- Electrostatic Discharge (ESD) Protection: Always wear a grounded anti-static wrist strap during handling to avoid damaging sensitive internal circuitry.
- Power Isolation Protocols: Complete electrical power-down must be verified prior to disconnecting or reconnecting ribbon cables. Never hot-plug connections.
- Operational Precision: Ensure the machine is completely de-energized prior to maintenance. Given the 6-inch wide print span, carefully balance the dual head-pressure toggles after installation to prevent uneven wear or ribbon drift. Use only lint-free swabs soaked in 99% isopropyl alcohol to wipe down the element array before running media.
- Certified Technician Requirement: Physical mounting and electrical alignment must be conducted exclusively by trained industrial service personnel.
Compatible Models & Systems
| Manufacturer / Brand | Verified Compatible Models & Systems |
|---|---|
| Honeywell | Datamax-O'Neil: |
Terms, Warranty & Customer Protection:
Pre-Installation Guarantee: 100% brand-new, factory-original product. Each unit is inspected and sealed before shipment. We guarantee authenticity and factory condition upon arrival.
Store Warranty Policy: 30 working days warranty covering manufacturing defects. Warranty claims require complete unboxing video and professional installation video performed by an experienced technician following standard recommended procedures.
Final Sale Conditions: Once the printhead has been exposed to ink or installed into a printer, it is considered used and cannot be returned or exchanged. Please verify compatibility and installation readiness before opening the sealed packaging.
