Original Roland DX4 Eco-Solvent Printhead (1000002201 / 6000005213)
- Write a review
$210.00
The Original Roland DX4 Eco Solvent Printhead is an authentic Japanese micro-piezo printhead designed for high-resolution, reliable eco-solvent and solvent printing across Roland, Mimaki, and Mutoh printers.
OEM Wide-Format Eco-Solvent Component
Original Roland DX4 Eco-Solvent Printhead (1000002201 / 6000005213)
OEM Part Numbers: 1000002201 / 6000005213 (Cross-Ref: Mimaki M004372 / M004905) | Dual-Channel MicroPiezo Drop-on-Demand (DoD) Solvent Printhead
Industrial DX4 Solvent Architecture & Fluid Passivation Notice
The Roland DX4 Eco-Solvent Printhead (part numbers 1000002201 and superseding 6000005213) is an authentic OEM MicroPiezo drop-on-demand replacement component engineered specifically for Roland wide-format printers and integrated print-and-cut plotters (VersaCAMM SP/VP Series, SOLJET Pro II / Pro III Series, and VersaArt). Built with solvent-resistant internal manifold seals and a dual-channel configuration, this unit is factory passivated to handle aggressive eco-solvent and mild-solvent inks (including Roland Eco-Sol MAX / MAX 2).
Product Overview
The Original Roland DX4 Eco-Solvent Printhead is an industrial-grade electro-mechanical component designed for high-resolution graphics on adhesive vinyl, banner material, canvas, backlit films, and heat transfer apparel media. Operating in multi-head configurations (up to 6 heads in SOLJET models), this module allows each unit to handle two independent ink colors simultaneously via twin fluid paths.
Featuring 360 active nozzles partitioned across 2 independent lines (180 nozzles per line), the DX4 delivers native optical resolutions up to 1440 DPI. Utilizing Variable Sized Droplet Technology (VSDT), it ejects precise micro-droplets starting at 3.5 picoliters up to larger volumes, producing smooth color gradations, razor-sharp vector text, and dense solid fills.
Part Information
| Product Name | Original Roland DX4 Eco-Solvent Printhead |
| OEM Manufacturer | Roland DG Corporation / Epson MicroPiezo Core (Japan) |
| Primary Roland Part Numbers | 1000002201 / 6000005213 |
| Cross-Platform Part References | Mimaki M004372 / M004905 | Mutoh MY-44743 / DF-43988 |
| Core Transducer Architecture | MicroPiezo DX4 Drop-on-Demand (DoD) Piezoelectric Platform |
| Component Classification | Industrial Solvent-Resistant 2-Channel Printhead Assembly |
| Channel Versatility | 2 Independent Inlets (Single color dual-channel or two distinct colors per head) |
| Ink Chemistry Pairing | Roland Eco-Sol MAX, Eco-Sol MAX 2, Mild Solvent, Aqueous Dye/Pigment, and Sublimation Inks |
| Country of Origin | Japan (100% Brand New in Factory Sealed Packaging) |
Technical Specifications
| Actuation Physics | Industrial MicroPiezo Drop-on-Demand (PZT Actuator System) |
| Active Addressable Nozzles | 360 nozzles total (2 parallel rows × 180 nozzles per line) |
| Nozzle Row Spacing & Pitch | 180 DPI native nozzle pitch per row (interleaved 360 DPI swathe coverage) |
| Droplet Size Modulation | Variable Sized Droplet Technology (VSDT): 3.5 pl (minimum) up to 21 pl (maximum) |
| Firing Frequency | 8 kHz nominal continuous firing frequency |
| Fluid Interface Porting | Dual solvent-passivated manifold nipples matched to standard DX4 solvent dampers |
| Electrical Interface | Dual 21-pin flat flexible cable (FFC) socket terminals with integrated grounding tab |
| Operating Temperature & Humidity | 18°C to 30°C (64°F to 86°F); 35% to 65% RH non-condensing |
| Dimensions & Net Weight | Approx. 85 × 42 × 30 mm; Net weight: ~78 g / Packaged weight: ~0.18 kg |
Key Features & Operational Advantages
- Solvent-Resistant Manifold Passivation: Internal micro-cavity bonding and manifold joints withstand aggressive eco-solvent carriers without channel delamination.
- 3.5-Picoliter Precision Firing: Produces photographic transitions and fine 2-point vector lines without dot graininess.
- Dual-Channel Ink Flexibility: Twin manifold nipples allow independent routing for two separate colors per head, enabling flexible CMYK, Lc, and Lm configurations.
- Direct Drop-In OEM Fitment: Built to factory tolerances, restoring original droplet trajectory and platen clearance without carriage modifications.
CRITICAL TECHNICAL & SERVICE ADVISORY
1. Mandatory Head-Rank ID Calibration: Following mechanical installation, the technician MUST enter the alphanumeric Head-Rank ID (printed on the barcode label) into the machine via Roland Service Mode. Running without registering the factory voltage rank leads to incorrect drop velocity, satellite misting, or premature piezo fatigue.
2. FFC Ribbon Cable Replacement: Always replace flat flexible data cables (FFC) when replacing a printhead. Creased, worn, or ink-contaminated cable leads can cause direct short circuits to the carriage board and blow mainboard onboard driver transistors or fuses.
3. Damper & O-Ring Replacement: Replace the ink dampers and rubber manifold O-rings concurrently with head installation. Restricted or aged dampers cause ink starvation during high-speed printing, while leaking O-rings risk dripping solvent directly onto electrical sockets.
4. Solvent Faceplate Maintenance: Never wipe the nozzle orifice plate with dry shop towels or abrasive materials. Clean only with lint-free foam swabs moistened with genuine Roland Eco-Sol MAX cleaning solution. Routinely service the rubber cap top and wiper blade to avoid dried solvent buildup around the nozzle row.
Compatible Models & Systems
| Series / Lineup | Compatible Printer Models | Head Configuration |
|---|---|---|
| Roland VersaCAMM SP Series | SP-300, SP-300V, SP-300i, SP-540V, SP-540i | 2-Head Array (CMYK) |
| Roland VersaCAMM VP Series | VP-300, VP-300i, VP-540, VP-540i | 4-Head Array (CMYK) |
| Roland SOLJET Pro II / Pro III | SJ-540, SJ-645EX, SJ-740, SJ-745EX, SJ-1000, SJ-1045EX, SC-540, SC-545EX, XC-540, XC-540MT, XJ-540, XJ-640, XJ-740 | 6-Head Staggered Array (CMYKLcLm) |
| Roland VersaArt & Advanced Jet | RS-540, RS-640, FP-740, CJ-540, FJ-540, FJ-640, FJ-740 | 4-Head / 6-Head Production |
| Roland VersaUV Benchtop & Flatbed | LEC-300, LEC-330, LEC-540, LEF-12, LEF-20, LEJ-640 | UV-Curable DX4 Configurations |
| Mimaki & Mutoh (Reference) | Mimaki JV3-130S/160S/250SP | Mutoh Rockhopper II/3, Spitfire, Blizzard | Shared DX4 Transducer Architecture |
*Compatibility Note: Specifically engineered for Roland eco-solvent and UV printers using DX4 technology. Verify printer carriage bracket and nozzle line color configuration prior to unpacking.
Terms, Warranty & Customer Protection
Condition: 100% Brand New, Genuine OEM Factory-Original Roland replacement printhead assembly in sealed factory packaging with shipping preservation fluid intact.
Warranty: Covered by standard OEM parts warranty against material and manufacturing defects out-of-box prior to ink introduction. No warranty applies once active solvent/UV ink or flush fluid has been introduced into the micro-fluidic chambers, or if damage results from head strikes, electrostatic discharge, or improper cable seating.
Returns: Unopened, factory-sealed boxes with intact tamper-evident seals are eligible for standard commercial return. Once the vacuum seal is broken, protective nozzle tape removed, or the head mounted onto a carriage frame, returns cannot be accepted due to fluid priming, static risk, and electrical contamination hazards.
