Konica KM1024i MHE-D 13PL 6988H Printhead Ð 1024 Nozzles, 13PL Drop Size for High-Speed UV, Oil, and Solvent Printing

The Konica KM1024i MHE-D 13PL Printhead is a robust, shear-mode, piezo on-demand printhead featuring an all-nozzle independent drive system with a multi-line structure. Unlike traditional 3-cycle system drives, this printhead enables simultaneous emission from all 1024 nozzles, enhancing positioning accuracy for high-definition print quality.

With a maximum drive frequency of 45kHz, approximately three times greater than the previous KM1024 Series, it is ideal for developing single-pass system inkjet printers capable of high-speed printing. The 13-picoliter drop size ensures sharp and precise images, making it suitable for detailed graphics and text.

Environmentally considerate, the KM1024i MHE-D incorporates only about one-third of the petroleum-derived materials and toxic chemicals used in earlier models, aligning with eco-friendly practices.

Compatible Printers

This printhead is compatible with various large-format and industrial printers, including:

• Agfa: Anapurna M2050i, Anapurna M2500i, Anapurna M3200i, Anapurna H2500i LED
• Allwin: S320UV, S500UV, UVT 2030, UVT 2512, UVT+ 2030, UVT+ 2512
• Docan: H1000
• Flora: HJ 5000UV
• Human Digital Technology: M-JET
• IIJ: ColourPrint-72
• JHF Vista: R3300, R6000, V300UV, V500UV
• Skyjet: FT2512i, FT3020i

Please verify compatibility with your specific printer model before purchasing.

Key Features

• High-Speed Performance: Independent drive system allows simultaneous emission from all 1024 nozzles, achieving a maximum drive frequency of 45kHz.
• High Resolution: 360 dpi native resolution ensures crisp and clear prints.
• Efficient Ink Usage: 13-picoliter drop size provides precise ink deposition for detailed images.
• Integrated Heater: Built-in heater enables stable temperature control for consistent performance with UV, oil, and solvent inks.

Specifications

• Technology: Piezo Drop On-Demand
• Native Resolution: 360 dpi
• Drop Size: 13 picoliters
• Number of Nozzles: 1024 (256 nozzles per line)
• Print Width: 72 mm
• Firing Frequency: 45 kHz
• Ink Compatibility: UV, oil, and solvent inks
• Heater: Integrated
• Dimensions: W131mm ? D18mm ? H94mm
• Weight: Approximately 150g

Encouragement to Buy

Upgrade your printing capabilities with the Konica KM1024i MHE-D 13PL Printhead. Its high-speed performance and precise ink deposition make it an excellent choice for professional UV, oil, and solvent-based printing applications. Don't miss outÑorder yours today!
