Datamax-O'Neil H-Class H-6308 H-6308X 300 DPI Thermal Printhead – PHD20-2244-01
- Write a review
$920.00
$533.60
Save 42%
Authentic OEM 300 DPI wide-format thermal replacement printhead for Datamax-O'Neil H-Class H-6308 and H-6308X industrial printers. Delivers 11.8 dots/mm high-definition output across a 6.4-inch print width for wide compliance and GHS hazard tags. Factory-certified assembly.
Product Overview
The Datamax-O'Neil PHD20-2244-01 is an authentic OEM 300 DPI (11.8 dots/mm) thermal printhead assembly designed for Datamax-O'Neil H-Class H-6308 and H-6308X 6-inch wide industrial printers. Engineered for automated packaging lines and wide-web compliance labeling requiring high-density graphics, GHS hazard pictograms, and sharp barcodes, it provides an active print swath of 6.4 inches (162.6 mm) at speeds up to 8 inches per second. Built on a rigid factory-aligned aluminum heatsink chassis, it provides direct field replacement for printheads degraded by open resistor elements, physical scoring, or thermal degradation.
Part Information
| Product Name | Datamax-O'Neil H-Class H-6308 H-6308X 300 DPI Thermal Printhead – PHD20-2244-01 |
| Manufacturer / Brand | Honeywell |
| OEM Part Number / Reference | OEM P/N: PHD20-2244-01 |
| Condition | 100% Genuine Original, Brand New, Factory Sealed |
| Product Status | Active OEM Production / Grade A Standard |
Technical Specifications
| Parameter | Technical Value / Specification |
|---|---|
| Technology | Direct Thermal / Thermal Transfer |
| Resolution / Channels | 300 DPI (11.8 dots/mm) |
| Print Width / Geometry | 6.4 inches (162.6 mm) |
| Operating Performance | High-Speed Jetting Standard |
| Technical Details & Notes | Resolution: 300 DPI (11.8 dots/mm); Maximum Print Width: 6.4 inches (162.6 mm); Printing Modes: Direct Thermal, Thermal Transfer; Element Pitch: 0.084 mm nominal; Maximum Speed: Up to 8 ips |
Master Comparison Matrix
| Model Variant | OEM Reference | Technology | Primary Application | Status |
|---|---|---|---|---|
| Datamax-O'Neil H-Class H-6308 H-6308X 300 DPI Thermal Printhead – PHD20-2244-01 (CURRENT PRODUCT) | OEM P/N: PHD20-2244-01 | Direct Thermal / Thermal Transfer | Industrial Production | Active Genuine |
Technical Precision & Operational Advisory
- Electrostatic Discharge (ESD) Protection: Always wear a grounded anti-static wrist strap during handling to avoid damaging sensitive internal circuitry.
- Power Isolation Protocols: Complete electrical power-down must be verified prior to disconnecting or reconnecting ribbon cables. Never hot-plug connections.
- Operational Precision: Ensure line power is completely isolated before servicing print carriage. Observe anti-static precautions; 300 DPI micro-resistors have high static sensitivity. Clean the printline with 99.7% isopropyl alcohol wipes before running media. Symmetrically balance head pressure across the wide carriage to prevent thermal ribbon wrinkling. Inspect the wide platen roller across its entire length to avoid point-load cracking of the ceramic substrate.
- Certified Technician Requirement: Physical mounting and electrical alignment must be conducted exclusively by trained industrial service personnel.
Compatible Models & Systems
| Manufacturer / Brand | Verified Compatible Models & Systems |
|---|---|
| Honeywell | Honeywell: |
Terms, Warranty & Customer Protection:
Pre-Installation Guarantee: 100% brand-new, factory-original product. Each unit is inspected and sealed before shipment. We guarantee authenticity and factory condition upon arrival.
Store Warranty Policy: 30 working days warranty covering manufacturing defects. Warranty claims require complete unboxing video and professional installation video performed by an experienced technician following standard recommended procedures.
Final Sale Conditions: Once the printhead has been exposed to ink or installed into a printer, it is considered used and cannot be returned or exchanged. Please verify compatibility and installation readiness before opening the sealed packaging.
OEM P/N: PHD20-2244-01
